The adhesive tape included on the sensors and cradles has been thoroughly tested and will not damage the battery jar.

I found this helpful (0)

Inaccurate? (0)

Answered by Anonymous

Power consumption depends on the number of sensors connected and the number of faults detected. The monitor consumes 0.36 watts; a single sensor consumes 0.024 watts with no faults. The total power consumption for common system configurations with no faults would be: •60-cell system: 0.36W + (60 * 0.024) = 1.44W •120-cell system: 0.36W + (120 * 0.024) = 2.88W •240-cell system: 0.36W + (240 * 0.024) = 5.76W The peak power consumption with 4+ Level & Temperature faults would increase the monitor to 1.44W: •60-cell system: 1.44W + (60 * 0.024) = 2.88W max •120-cell system: 1.44W + (120 * 0.024) = 4.32W max •240-cell system: 1.44W + (240 * 0.024) = 7.2W max

I found this helpful (0)

Inaccurate? (0)

Answered by Anonymous

A: Each ELM kit includes (1) roll of cleaning towels and (1) can of CRC PF Precision Cleaner. It is essential to clean the cells with the included cleaning kit to prevent the sensors from falling of the cells. One cleaning towel should be used to clean no more than (4) cells and one can of cleaning spray is good for up to 240 cells.

I found this helpful (0)

Inaccurate? (0)

Answered by Anonymous

The clearances are based on distance above and below the "minimum" line on the battery jar. The sensor frame can be removed to decrease the required clearances. Minimum height without frame: 29 mm (1 1/8th") Typical height with frame: 35 mm (1 3/8th") Minimum depth: 32 mm (1 1/4").

I found this helpful (0)

Inaccurate? (0)

Answered by Anonymous

The electrolyte level sensor must be mounted vertically in the upright position. It must be flat on the surface of the jar with the "level" line on the sensor in line with the "minimum" line on the jar.

I found this helpful (0)

Inaccurate? (0)

Answered by Anonymous

Common applications include but are not limited to: •Power Utilities •Telecommunications •CATV / Broadband •Mission Critical Facilities •UPS Systems •Generation & Distribution •Financial Institutions •Oil, Gas & Fuel •Mining •Government/Defense •Transportation Operations •Hospitals •Emergency Lighting •Green Energy •Call Centers •Battery Suppliers and Manufacturers •Battery Service Groups •Medical/Biotechnology •Generators

I found this helpful (0)

Inaccurate? (0)

Answered by Anonymous

The ELM does not include an audible alarm but it is possible to use an external one. The contacts on the warning outputs are completely isolated from each other and the sensor circuits, therefor you can drive any circuit with them, lights, audible alarms, motors, pumps etc. The contacts are rated at 15 amps for 125 VAC or 10 amps at 277 VAC. There is a rating of 2KV between the contacts and coil (the coil is connected to the sensor circuits).

I found this helpful (0)

Inaccurate? (0)

Answered by Anonymous

The electrolyte level monitor uses a high sensitivity temperature IC mounted in the case.

I found this helpful (0)

Inaccurate? (0)

Answered by Anonymous

A: An electrolyte level alarm occurs if low level electrolyte is detected for more than 40 minutes (to prevent spontaneous alarming). When a level alarm is active, it will remain so until the electrolyte level is restored and the R/S button is manually pressed on the sensor. The temperature alarm occurs as soon as the threshold temperature is detected, it will reset automatically after 4 minutes.
