PosiTector Advanced FS3 Inspection Kit with Case
PosiTector Inspection Kits contain a PosiTector gage body (Standard or Advanced) with 3 probes-coating thickness, environmental and surface profile-and accessories in a convenient hard shell carrying case.
The PosiTector gage body accepts all PosiTector 6000, 200, RTR, SPG, DPM, SST, SHD, BHI and UTG probes easily converting from a coating thickness gage to a surface profile gage, dew point meter, soluble salt tester, hardness tester, or ultrasonic wall thickness gage.
Advanced Model Inspection Kits
Each Advanced Kit contains a PosiTector Advanced gage body and 3 probes-coating thickness, environmental, and surface profile.
Features include:
- Touchscreen keyboard for renaming batches, adding notes, and more
- Live graphing of measurement data
- WiFi technology wirelessly synchronizes with PosiSoft.net and downloads software updates
- Bluetooth 4.0 Technology for data transfer to a mobile device running the PosiTector App or optional portable printer. BLE API available for integration into third-party software.
Coating Thickness measurement with Advanced models
- Storage of 250,000 readings from multiple probes in up to 1,000 batches and sub-batches
- Prompted Batch Mode-create pre-defined batches with on-screen text and image prompts for each reading
- 3 Scan Modes-increase measurement speed to 180+ readings per minute
- Normal – take continuous readings without lifting the probe
- Statistics – take continuous readings and record average, standard deviation, min/max thickness and number of readings while scanning
- Limited Count Average – take continuous readings up to a user-specified count. The gage displays and records the average of the readings.
- SSPC-PA 2, ISO 19840, and IMO PSPC 90:10 features determine if film thickness over a large area conforms to user-specified min/max levels
Environmental Monitoring with Advanced models
- Storage of 250,000 datasets from multiple probes in up to 1,000 batches
- Enhanced Auto Log mode turns the gage off between readings for up to 8 months of battery life. Each reading can be uploaded to PosiSoft.net or an FTP server using WiFi. Automatically group readings into batches at daily, weekly, or monthly intervals
- User defined alarms for all parameters-visible and audible warnings. Receive email alerts when connected to WiFi
- Trend Charts graph readings in real-time
Surface Profile measurement with Advanced models
- NEW Storage of 250,000 readings from multiple probes in up to 1,000 batches and sub-batches
- SmartBatchTM allows entry of user-defined parameters and criteria to comply with standards such as ASTM D4417 and SSPC PA-17
